Product name:Digital Outside Micrometers
Type:Outside Micrometers 0-25mm
Division value:0.01mm
Measuring range:0-25mm
Moq:10pieces
Dip stick:carbide
Measuring type:Outside Micrometers
| 订单号 Order No. | 测量范围 Range (mm) | 分度值 Grad (mm) | 精度 Accuracy (mm) | 备注 | ||
| 400-505 | 400-505M | 401-505 | 0-25mm | 0.001mm | ±4μm | 带游标读数 |
| 400-510 | 400-510M | 401-510 | 25-50mm | 0.001mm | ±4μm | 带游标读数 |
| 400-515 | 400-515M | 401-515 | 50-75mm | 0.001mm | ±5μm | 带游标读数 |
| 400-520 | 400-520M | 401-520 | 75-100mm | 0.001mm | ±5μm | 带游标读数 |
| 400-100 | 400-100M | 501-100 | 0-15mm | 0.001mm | ±4μm | |
| 400-105 | 400-105M | 401-105 | 0-25mm | 0.001mm | ±4μm | |
| 400-110 | 400-110M | 401-110 | 25-50mm | 0.001mm | ±4μm | |
| 400-115 | 400-115M | 401-115 | 50-75mm | 0.001mm | ±5μm | |
| 400-120 | 400-120M | 401-120 | 75-100mm | 0.001"/0.001" | ±5μm | |
| 400-205 | 400-205M | 401-205 | 0-1" | 0.001"/0.001" | ±0.00015" | |
| 400-210 | 400-210M | 401-210 | 1-2" | 0.001"/0.001" | ±0.00015" | |
| 400-215 | 400-215M | 401-215 | 2-3" | 0.001"/0.001" | ±0.0002" | |
| 400-220 | 400-220M | 401-220 | 3-4" | 0.001"/0.001" | ±0.0002" | |
