Main technical parameters
ZCYQ80B one-way punch former
Center height: 80 mm
Clamping diameter in V-groove: 4-30 mm
Stroke of V-block: 25 mm
Number of teeth: 24
Maximum wheel diameter: 200 mm
Maximum radius when dressing arc: convex: r50 mm, concave: r100 mm
The punch former is suitable for surface grinders or universal grinders for grinding circular, radius and multi-angle punches and precise EDM electrodes. The center hole allows long-time punch use. With its radius dresser arm, it is able to dress the wheel into different straight, arc profiles. ZCYQ80C punch former
3-jaw chuck hole diameter: 16 mm
Minimum clamping diameter: 2 mm
Maximum clamping diameter: 70 mm
ZCYQ80C
The ZCYQ80C punch former comes with 3 jaws for fast and easy fixation of the workpiece. It can also adjust the center of the 3 jaws. Suitable for batch production.
ZCYQ80D ER Collet Punch
Clamping diameter: 2-20
Supply ER32 collet sizes: 4, 6, 8, 10, 12, 16, 20
For workpieces with a diameter less than 4 mm, use a shank 20 mm/ER16 collet chuck.
When machining, the workpiece can be clamped quickly and stably without checking the center.
